TPS61236PRWLR
Manufacturer:
Texas Instruments
Mfr.Part #:
TPS61236PRWLR
Datasheet:
Description:
Voltage Regulators - Switching VQFN-9 LLC(QFN) Boost Adjustable 2.9 V to 5.5 V
| Parameter | Value |
|---|---|
| Length | 2.5 mm |
| Width | 2.5 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 9 |
| Height | 1 mm |
| Thickness | 0.9 mm |
| Lifecycle Status | Active |
| Quiescent Current | 10 µA |
| Number of Outputs | 1 |
| Output Current | 8 A |
| Output Voltage | 2.9 V to 5.5 V |
| Switching Frequency | 1 MHz |
| Max Input Voltage | 4.9 V |
| Min Input Voltage | 2.3 V |
| Output Type | Adjustable |
| Topology | Boost |
| RoHS | Compliant |
| Packaging | Reel |
| Function | Step-Up |
Stock: 603
Distributors
pcbx
pcbxUnit Price$1.12963
Ext.Price$1.12963
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.12963 | $1.12963 |
| 10 | $0.90672 | $9.06720 |
| 25 | $0.79903 | $19.97575 |
| 50 | $0.70413 | $35.20650 |
| 100 | $0.62051 | $62.05100 |
| 300 | $0.58665 | $175.99500 |
| 500 | $0.55465 | $277.32500 |
| 1000 | $0.52099 | $520.99000 |
